The CMP 150™ generator series offers high quality radiographic capabilities delivering ample output power and extended mAs operation with superior performance and reliability, powered by a standard wall receptacle of any country. This generator caters to value DR applications such as chest screening, chiropractic care, basic radiographic systems in emerging markets, and veterinary practices across the world.


Main Features

  • RAD-X CMP150 15 amp 32kW High Frequency Generator.
  • Capacitor energy storage to assist power delivery
  • 125kV 40 – 125kV in 1 kV increments.
  • 400mA 25,50,75,100,150,200,250,300 and 400mA selections.
  • Time Selections 0.002 – 6 Seconds.
  • mAs selections up to 600mAs.
  • Factor selection choices
    • 3 Point control – kV, mA and time.
    • 2 Point control – kV and mAs.
    • APR – Anatomical Programs – 12 Anatomical Regions, just select the region, select view, enter subject thickness in cm and expose.
    • Fully adjustable to suit you film screen combination.
    • Control Console mounting – options for wall or bench.
  • High frequency waveform gives shorter exposure times, lower subject dose and greater accuracy, exposure to exposure.
  • Microprocessor control provides increased consistency and efficient operation.
  • Extended x-ray tube life through advanced protection circuitry.
  • Onboard self-diagnostics – advanced system protection, increased serviceability.
