Vscan Air™ SL-imgVscan Air™ SL-img

Vscan Air™ SL

Sector phased array and linear array dual-probe handheld ultrasound.

Vscan Air SL sets a new standard in handheld ultrasound — a flexible, wireless dual-probe with sector and linear transducers that deliver crystal clear images anytime, anywhere. Well suited for rapid cardiac and vascular assessments.

Specifications

Main Features

Imaging modes

  • B-mode
  • Color Doppler
  • M-mode
  • Pulsed Wave Doppler

Battery life

  • Scan time: up to 50 minutes
  • Recharge time: 75 minutes (from 10% to 90%)
  • Use supplied wireless charger or any
  • Qi-certified charger
  • Smart connect pairing: probe stays connected to your display device while charging
  • Customizable probe button
  • Freeze or store
TWO TRANSDUCERS IN ONE PROBE:
Linear transducer for shallow scanning

  • Frequency: 3 – 12 MHz
  • Maximum depth: 8 cm

Curved transducer for deep scanning

  • Frequency: 2 – 5 MHz
  • Maximum depth: 8 cm

Durability

  • Tested to military drop standards (MIL-810G)
  • IP67 rated waterproof
  • Compatible with high-level disinfection techniques
  • Withstands temperature extremes

Portability

  • Weight: 205 +/- 3 grams
  • Mobile App enabled on Apple® and Android™ devices
  • Probe is completely cordless
  • Wireless data connectivity

Additional information

Dimensions 141 × 67 × 33 mm
